Name: Milwaukee M18 CHM-0C FUEL 5 Kg SDS-Max Drilling And Breaking Hammer 4933451362
Brand: Milwaukee
SKU: SKU250626194620003
Availability: InStock

Milwaukee M18 CHM-0C FUEL 5 Kg SDS-Max Drilling And Breaking Hammer 4933451362

SKU: SKU250626194620003 EAN: 4002395159208 Milwaukee

Product Description

Glomar Trading - Defining Trade Excellence.

Condition
New: A genuine product, unused and unopened in original packaging.

Main Product Information
Brand	Milwaukee
Model	M18 CHM
MPN	4933451362
EAN	4002395159208
Product Category	Power Tools \| Drilling and Chipping \| SDS Max

Description

Specifications
Blow energy (EPTA)(J)	6.1
Fits MILWAUKEE® Dust Extractors	PHDE72
Full load hammer action (bpm)	0 - 3000
Max. drilling concrete (mm)	40
Max. drilling core bit (mm)	100
Max. drilling tunnel bit (mm)	65
No load speed (rpm)	0 - 450
Optimised drilling capacity in concrete (mm)	16 - 32
Standard equipment	Side handle
Supplied in	Kitbox
Tool reception	SDS-Max
Article Number	4933451362
EAN	4002395159208
Battery pack capacity (Ah)	No batteries supplied
Battery type	Li-ion
Charger included	No charger supplied
Charger supplied	No charger supplied
No. of batteries supplied	0
Voltage (V)	18
Weight with battery pack (EPTA) (kg)	7.1 (M18 HB12)
Sound power level (Lwa)(dB(A))	104.6
Sound power level uncertainty (dB(A))	3
Sound pressure level (Lpa)(dB(A))	93.6
Sound pressure level uncertainty (dB(A))	3
Vibration chiseling (m/s²)	10.63
Vibration chiselling uncertainty (m/s²)	1.5
Vibration drilling (m/s²)	11.03
Vibration drilling into concrete [m\|s²]	11.03
Vibration drilling into concrete uncertainty [m\|s²]	1.5

What's Included
1x M18 FUEL™ 5 kg SDS-Max drilling and breaking hammer (Model: None) 1x Kitbox (Model: None) 1x Kitbox (Model: None)

Spare Parts

Part Code	Description	Quantity

4931431199	WASHER	1
4931435133	CAP	1
4931435134	HOLDING RING	1
4931435135	BACKING FLANGE	1
4931435137	WASHER	1
4931435138	COLLAR	1
4931435139	INTERLOCK SLEAVE	1
4931435140	SPRING	1
4931435141	PROTECTION WASHER	1
4931435142	BEARING END PLATE	1
4931435143	O-RING	1
4931435144	CAM	2
4931435145	PERCUSSION BODY	1
4931435146	SPINDLE SLEEVE	1
4931435147	SNAP DIE	1
4931435148	DISC	1
4931435149	AUXILIARY HANDLE	1
4931435150	SCREW	3
4931435155	SEAL	1
4931435156	PLATE	1
4931435158	SCREW	6
4931435163	BEVEL GEAR	1
4931435164	SLEEVE	1
4931435165	INTERLOCK PLATE	1
4931435166	PISTON AND CON ROD ASSY	1
4931435168	NEEDLE BEARING	2
4931435169	WASHER	1
4931435192	PROTECTION WASHER	1
4931435195	DRIVER	1
4931435196	STOP WASHER	1
4931435197	RING	2
4931435198	RING	1
4931435199	PIN	14
4931435200	RING	1
4931435201	DISC	1
4931435202	SPINDLE SLEEVE	1
4931435203	O-RING	2
4931435204	CLAMP	1
4931435205	NUT	1
4931435206	HANDLE	1
4931435207	HANDLE	1
4931435353	RUBBER CAP	1
4931435354	O-RING	2
4931435360	DAMPING RING	2
4931446171	FORK	1
4931453590	HOUSING	1
4931453591	GEAR BOX	1
4931453592	DRIVE GEAR	1
4931453593	GEAR BOX	1
4931453594	TURNING KNOB	1
4931453595	CRANK ASSEMBLY	1
4931453596	ARMATURE ASSEMBLY	1
4931453597	SWITCH ASSEMBLY	1
4931453598	HOUSING SET ASSY	1
4931453599	SCREW	4
4931453600	INTERLOCK ELEMENT	1
4931453601	PAIR HANDLE SHELLS	1
4931453602	RATING PLATE	1
4931453604	CARRYING CASE	1
4931453845	PACKING SET	1
4931473724	CARRYING CASE	2
4931624375	GEAR GREASE	2
633152001	PLATE	1
633234001	HOLDING PLATE	1

Specifications

Battery Included	No
Battery Technology	Lithium-Ion (Li-Ion)
Brand	Milwaukee
Chuck Size	TBA
Chuck Type	TBA
Colour	Red
Country/Region of Manufacture	TBA
Features	TBA
Item Diameter	TBA
Item Height	TBA
Item Length	TBA
Item Weight	TBA
Item Width	TBA
Manufacturer Warranty	TBA
Maximum Speed	TBA
Minimum Speed	TBA
Model	M18 CHM
Motor Type	TBA
MPN	4933451362
Number of Batteries	TBA
Number of Pieces	TBA
Power Source	TBA
Type	SDS Max
Unit Quantity	1
Unit Type	Unit
Voltage	18
