Milwaukee JS 120 X Heavy Duty Body Grip Jigsaw 4933381680
SKU: SKU250626193502002
EAN: 4002395234677
Milwaukee
Price Comparison
No recent prices available for this product
Prices are updated regularly. Please check back later.Product Description
| Condition | |
|---|---|
| New: A genuine product, unused and unopened in original packaging. |
| Main Product Information | |
|---|---|
| Brand | Milwaukee |
| Model | JS 120 X |
| MPN | 4933381680 |
| EAN | 4002395234677 |
| Product Category | Power Tools | Sawing and Cutting | Jigsaws |
| Description | |
|---|---|
| Specifications | |
|---|---|
| Max. cutting capacity aluminium (mm) | 30 |
| Max. cutting capacity steel (mm) | 10 |
| Max. cutting capacity wood (mm) | 120 |
| Max. cutting capacity wood/ steel/ aluminium (mm) | 120/ 10/ 30 |
| Mitre capacity (°) | 45 |
| No load stroke rate (spm) | 500 - 2800 |
| Power input (W) | 710 |
| Standard equipment | 4 m cable, 5 saw blades, anti-splintering device, sliding shoe, dust cap, absorption adaptor |
| Stroke length (mm) | 26 |
| Supplied in | Kitbox |
| Article Number | 4933381680 |
| EAN | 4002395234677 |
| Weight (kg) | 2.3 |
| Sound power level (Lwa)(dB(A)) | 98 |
| Sound power level uncertainty (dB(A)) | 3 |
| Sound pressure level (Lpa)(dB(A)) | 87 |
| Sound pressure level uncertainty (dB(A)) | 3 |
| Vibration cutting metal (m/s²) | 10 |
| Vibration cutting metal uncertainty (m/s²) | 1.5 |
| Vibration cutting wood (m/s²) | 10.5 |
| Vibration cutting wood uncertainty (m/s²) | 1.5 |
| What's Included | |
|---|---|
|
| Spare Parts | ||
|---|---|---|
 | ||
| Part Code | Description | Quantity |
|---|---|---|
| 4931206687 | CABLE ENTRY SLEEVE | 1 |
| 4931219422 | NEEDLE BEARING | 2 |
| 4931300699 | SCREW | 1 |
| 4931306351 | RUBBER SLEEVE | 1 |
| 4931310396 | SCREW | 4 |
| 4931330051 | HOLDER | 1 |
| 4931330301 | TORSION SPRING | 1 |
| 4931330303 | CENTERING JAW | 2 |
| 4931330437 | SPRING | 1 |
| 4931330474 | PLATE SPRING | 1 |
| 4931330494 | COLLET | 1 |
| 4931330633 | FAN | 1 |
| 4931357000 | FELT WASHER | 1 |
| 4931357489 | GUIDE PIECE | 1 |
| 4931357515 | GEAR | 1 |
| 4931357522 | ROCKER BAR | 1 |
| 4931357525 | RAM | 1 |
| 4931357534 | ELECTRIC FIELD | 1 |
| 4931357548 | BRUSH MODULE | 1 |
| 4931357552 | DUST CAP | 1 |
| 4931357577 | SHIM | 1 |
| 4931357583 | CYLINDER PIN | 1 |
| 4931357584 | WIRE STRAP | 1 |
| 4931357588 | PRESSURE ELEMENT | 1 |
| 4931357598 | SCREW | 1 |
| 4931357605 | SLIDE PLATE | 1 |
| 4931357648 | ARMATURE | 1 |
| 4931357686 | PRESSURE SPRING | 1 |
| 4931357893 | PILLOW BLOCK | 1 |
| 4931357983 | SUCTION SLEEVE | 1 |
| 4931361376 | NEEDLE BUSH | 1 |
| 4931378812 | SWITCH HANDLE | 1 |
| 4931378813 | SLEEVE | 1 |
| 4931381103 | INDEXING BOLT | 1 |
| 4931381109 | BALANCE WEIGHT | 1 |
| 4931381298 | SLIDER | 1 |
| 4931381610 | TENSION LEVER | 1 |
| 4931381682 | HOUSING | 1 |
| 4931381729 | ELECTRONIC | 1 |
| 4931385824 | SWITCH | 1 |
| 4931392597 | CARBON BRUSH SET | 1 |
| 4931412827 | GROUND PLATE | 1 |
| 4931415345 | CARRYING CASE | 1 |
| 4931476718 | RATING PLATE | 1 |
| 4931605092 | RING D471 6X0,7 | 1 |
| 4931621830 | DISC N874237 6,1X12X0,5 | 1 |
| 4931621834 | WASHER | 1 |
| 4931621888 | PIN D 6325 4M6X28 | 1 |
| 4931622131 | DISC | 1 |
| 4931623102 | SCREW | 1 |
| 4931623618 | CONNECTION CABLE | 1 |
| 4931624515 | SCREW N874101-1 SHR H-K4X18 T15 | 9 |
| 4931902888 | BALL BEARING | 1 |
| 4932357682 | ANT-CHIPPING DEVICE (3 PCS) P1 A/M | 1 |
| 4932357881 | GUIDE SHOE JSPE90X P1 A/M | 1 |
Specifications
| Battery Capacity | TBA |
| Battery Included | No |
| Battery Technology | Lithium-Ion (Li-Ion) |
| Blade Length | TBA |
| Blade Location | TBA |
| Blade Strength | TBA |
| Brand | Milwaukee |
| Cable Length | TBA |
| Charging Time | TBA |
| Colour | Red |
| Country/Region of Manufacture | TBA |
| Cutting Angle | TBA |
| Cutting Depth | TBA |
| Item Diameter | TBA |
| Item Height | TBA |
| Item Length | TBA |
| Item Weight | TBA |
| Item Width | TBA |
| Manufacturer Warranty | TBA |
| Model | JS 120 X |
| Motor Type | TBA |
| MPN | 4933381680 |
| Number of Batteries | TBA |
| Number of Items in Set | TBA |
| Power Source | TBA |
| Safety Type IP | TBA |
| Set Includes | TBA |
| Suitable For | TBA |
| Type | Jigsaws |
| Unit Quantity | 1 |
| Unit Type | Unit |
| Voltage | TBA |
