Milwaukee K 540 S 5 Kg Class Drilling And Breaking Hammer 4933418100
SKU: SKU250626193453001
EAN: 4002395238422
Milwaukee
Price Comparison
No recent prices available for this product
Prices are updated regularly. Please check back later.Product Description
| Condition | |
|---|---|
| New: A genuine product, unused and unopened in original packaging. |
| Main Product Information | |
|---|---|
| Brand | Milwaukee |
| Model | K 540 S |
| MPN | 4933418100 |
| EAN | 4002395238422 |
| Product Category | Power Tools | Drilling and Chipping | SDS Max |
| Description | |
|---|---|
| Specifications | |
|---|---|
| Blow energy (EPTA)(J) | 7.5 |
| Full load hammer action (bpm) | 3000 |
| Full load speed (soft hammer) (rpm) | 430 |
| Max. drilling concrete (mm) | 40 |
| Max. drilling core bit (mm) | 105 |
| Max. drilling tunnel bit (mm) | 65 |
| No load speed (rpm) | 450 |
| Power input (W) | 1100 |
| Standard equipment | Additional handle, grease |
| Supplied in | Kitbox |
| Tool reception | SDS-Max |
| Article Number | 4933418100 |
| EAN | 4002395238422 |
| Weight (kg) | 6.3 |
| Sound power level (Lwa)(dB(A)) | 104 |
| Sound power level uncertainty (dB(A)) | 3 |
| Sound pressure level (Lpa)(dB(A)) | 93 |
| Sound pressure level uncertainty (dB(A)) | 3 |
| Vibration chiseling (m/s²) | 12.8 |
| Vibration chiselling uncertainty (m/s²) | 1.5 |
| Vibration drilling (m/s²) | 17.4 |
| Vibration drilling into concrete [m|s²] | 17.4 |
| Vibration drilling into concrete uncertainty [m|s²] | 1.5 |
| What's Included | |
|---|---|
|
| Spare Parts | ||
|---|---|---|
 | ||
| Part Code | Description | Quantity |
|---|---|---|
| 1000063920 | PART NOT DEATAILED | 1 |
| 4931431199 | WASHER | 1 |
| 4931435132 | RUBBER CAP | 1 |
| 4931435133 | CAP | 1 |
| 4931435134 | HOLDING RING | 1 |
| 4931435135 | BACKING FLANGE | 1 |
| 4931435136 | SEAL RING | 2 |
| 4931435137 | WASHER | 1 |
| 4931435138 | COLLAR | 1 |
| 4931435139 | INTERLOCK SLEAVE | 1 |
| 4931435140 | SPRING | 1 |
| 4931435141 | PROTECTION WASHER | 1 |
| 4931435142 | BEARING END PLATE | 1 |
| 4931435143 | O-RING | 1 |
| 4931435144 | CAM | 2 |
| 4931435145 | PERCUSSION BODY | 1 |
| 4931435146 | SPINDLE SLEEVE | 1 |
| 4931435147 | SNAP DIE | 1 |
| 4931435148 | DISC | 1 |
| 4931435149 | AUXILIARY HANDLE | 1 |
| 4931435150 | SCREW | 3 |
| 4931435151 | RETAINER | 1 |
| 4931435152 | GEAR BOX ASSY | 1 |
| 4931435153 | BEARING KIT | 1 |
| 4931435154 | WORM GEAR WHEEL | 1 |
| 4931435155 | SEAL | 1 |
| 4931435156 | PLATE | 1 |
| 4931435157 | FORK | 1 |
| 4931435158 | SCREW | 6 |
| 4931435159 | GEAR BOX | 1 |
| 4931435160 | KNOB | 1 |
| 4931435161 | O-RING | 2 |
| 4931435162 | SCREW | 1 |
| 4931435163 | BEVEL GEAR | 1 |
| 4931435164 | SLEEVE | 1 |
| 4931435165 | INTERLOCK PLATE | 1 |
| 4931435166 | PISTON AND CON ROD ASSY | 1 |
| 4931435167 | EXCENTER | 1 |
| 4931435168 | NEEDLE BEARING | 2 |
| 4931435169 | WASHER | 1 |
| 4931435170 | BALL BEARING | 1 |
| 4931435171 | MOTOR PLATE | 1 |
| 4931435174 | AIR DEFLECTOR RING | 1 |
| 4931435175 | MOTOR COVER | 1 |
| 4931435176 | SCREW | 4 |
| 4931435177 | CARBON BRUSH | 1 |
| 4931435179 | CARBON BRUSH | 1 |
| 4931435181 | BRUSH HOLDER | 2 |
| 4931435182 | FIELD LEAD GROMMET | 1 |
| 4931435183 | SCREW | 2 |
| 4931435184 | SWITCH | 1 |
| 4931435185 | ELECTRIC COMPLETE | 1 |
| 4931435187 | CONNECTION CABLE | 1 |
| 4931435190 | CORD GRIP | 1 |
| 4931435191 | HOUSING SET ASSY | 1 |
| 4931435192 | PROTECTION WASHER | 1 |
| 4931435193 | MOTOR ASSEMBLY | 1 |
| 4931435195 | DRIVER | 1 |
| 4931435196 | STOP WASHER | 1 |
| 4931435197 | RING | 1 |
| 4931435198 | RING | 1 |
| 4931435199 | PIN | 6 |
| 4931435200 | RING | 1 |
| 4931435201 | DISC | 1 |
| 4931435202 | SPINDLE SLEEVE | 1 |
| 4931435203 | O-RING | 2 |
| 4931435204 | CLAMP | 1 |
| 4931435205 | NUT | 1 |
| 4931435206 | HANDLE | 1 |
| 4931435207 | HANDLE | 1 |
| 4931435208 | RATING PLATE | 1 |
| 4931435211 | CARRYING CASE | 1 |
| 4931446718 | MAINTENANCE SET | 1 |
| 4931494482 | SERVICE-KIT | 1 |
| 633152001 | PLATE | 1 |
| 633234001 | HOLDING PLATE | 1 |
| 660024018 | SCREW | 4 |
| 661189001 | SCREW | 2 |
| 790009001 | CONNECTOR | 1 |
Specifications
| Application | TBA |
| Brand | Milwaukee |
| Colour | Red |
| Country/Region of Manufacture | TBA |
| Item Depth | TBA |
| Item Diameter | TBA |
| Item Height | TBA |
| Item Length | TBA |
| Item Weight | TBA |
| Item Width | TBA |
| Manufacturer Warranty | TBA |
| Material | TBA |
| Model | K 540 S |
| MPN | 4933418100 |
| Number of Items in Set | TBA |
| Package Quantity | TBA |
| Suitable For | TBA |
| Type | SDS Max |
| Unit Quantity | 1 |
| Unit Type | Unit |
