Milwaukee DD 3-152 3-speed Combi Diamond Drill 4933428000
SKU: SKU250626193359002
EAN: 4002395239801
Milwaukee
Price Comparison
No recent prices available for this product
Prices are updated regularly. Please check back later.Product Description
| Condition | |
|---|---|
| New: A genuine product, unused and unopened in original packaging. |
| Main Product Information | |
|---|---|
| Brand | Milwaukee |
| Model | DD 3-152 |
| MPN | 4933428000 |
| EAN | 4002395239801 |
| Product Category | Power Tools | Drilling and Chipping | Diamond Drilling |
| Description | |
|---|---|
| Specifications | |
|---|---|
| Full load speed (rpm) | 550 / 1250 / 2700 |
| Max. drilling concrete (mm) | 152 |
| Max. drilling masonry (mm) | 202 |
| Power input (W) | 1900 |
| Supplied in | Kitbox |
| Tool reception | ½″ G + 1 ¼″ UNC |
| Article Number | 4933428000 |
| EAN | 4002395239801 |
| Weight (kg) | 6.5 |
| Sound power level (Lwa)(dB(A)) | 95 |
| Sound power level uncertainty (dB(A)) | 3 |
| Sound pressure level (Lpa)(dB(A)) | 84 |
| Sound pressure level uncertainty (dB(A)) | 3 |
| Vibration drilling into brick and tile (m/s²) | 16.3 |
| Vibration drilling into brick and tile uncertainty (m/s²) | 2 |
| Vibration drilling into concrete [m|s²] | 14.1 |
| Vibration drilling into concrete uncertainty [m|s²] | 2 |
| What's Included | |
|---|---|
|
| Spare Parts | ||
|---|---|---|
 | ||
| Part Code | Description | Quantity |
|---|---|---|
| 4931402576 | CARRYING CASE | 1 |
| 4931428005 | INSERT | 1 |
| 4931428009 | SPANNER | 1 |
| 4931428010 | SPANNER 41mm | 1 |
| 4931428015 | ARMATURE | 1 |
| 4931428016 | ELECTRIC FIELD | 1 |
| 4931428017 | MOTOR HOUSING | 1 |
| 4931428018 | AIR DEFLECTOR RING | 1 |
| 4931428019 | CARBON BRUSH SET | 1 |
| 4931428036 | BEARING COVER | 1 |
| 4931428038 | PRINTED CIRCUIT | 1 |
| 4931428039 | CABLE SET | 1 |
| 4931428040 | SWITCH LEVER | 1 |
| 4931428041 | INTERFERENCE SUPPR. | 1 |
| 4931428042 | SWITCH | 1 |
| 4931428043 | CONNECTION CABLE | 1 |
| 4931428044 | PROTECTING COVER | 1 |
| 4931428045 | GROOVED BALL BEAR. | 1 |
| 4931428046 | GEAR ENDPLATE | 1 |
| 4931428047 | SEAL | 1 |
| 4931428048 | SEAL RING | 1 |
| 4931428049 | NEEDLE BUSH | 2 |
| 4931428553 | GEAR BOX HOUSING | 1 |
| 4931428554 | Supporting plate with 2 hex. sock. screw | 1 |
| 4931428555 | HOLDING DEVICE | 1 |
| 4931428556 | CLUTCH | 1 |
| 4931428557 | SPINDLE | 1 |
| 4931428558 | PARALLEL KEY | 1 |
| 4931428559 | GROOVED BALL BEAR. | 1 |
| 4931428560 | PROTECTION WASHER | 1 |
| 4931428561 | PROTECTION WASHER | 1 |
| 4931428562 | PROTECTION WASHER | 1 |
| 4931428563 | SEAL RING | 1 |
| 4931428564 | STRIPPER | 2 |
| 4931428565 | SPACER | 1 |
| 4931428566 | SEAL RING | 1 |
| 4931428567 | WHEEL | 1 |
| 4931428568 | SPRING RING | 1 |
| 4931428569 | JUMPER RING | 1 |
| 4931428570 | WHEEL | 1 |
| 4931428571 | SPRING RING | 1 |
| 4931428572 | SEAL RING | 1 |
| 4931428573 | HANDLE | 1 |
| 4931428574 | SWITCH LEVER | 1 |
| 4931428578 | ADAPTOR | 1 |
| 4931428579 | VALVE | 1 |
| 4931428580 | BRUSH HOLDER PAIR | 1 |
| 4931428581 | CONNECTOR | 1 |
| 4931428582 | GREASE DEPOSIT | 1 |
| 4931428583 | HANDLE SHELLS | 1 |
| 4931428584 | GEAR ENDPLATE | 1 |
| 4931428585 | GEAR OIL 1L | 1 |
| 4931428586 | CONNECTION SLEEVE | 1 |
| 4931428587 | BOLT SET | 1 |
| 4931428588 | STICKER | 1 |
Specifications
| Auxiliary Handle | TBA |
| Battery Capacity | TBA |
| Battery Included | No |
| Battery Technology | Lithium-Ion (Li-Ion) |
| Brand | Milwaukee |
| Cable Length | TBA |
| Charging Time | TBA |
| Chuck Size | TBA |
| Chuck Type | TBA |
| Colour | Red |
| Country/Region of Manufacture | TBA |
| Features | TBA |
| Item Diameter | TBA |
| Item Height | TBA |
| Item Length | TBA |
| Item Weight | TBA |
| Item Width | TBA |
| Manufacturer Warranty | TBA |
| Maximum Torque | TBA |
| Model | DD 3-152 |
| Motor Type | TBA |
| MPN | 4933428000 |
| Number of Batteries | TBA |
| Number of Items in Set | TBA |
| Power | TBA |
| Power Source | TBA |
| Set Includes | TBA |
| Speed | TBA |
| Type | Diamond Drilling |
| Unit Quantity | 1 |
| Unit Type | Unit |
| Voltage | TBA |
